Monument Drive Commuter Parking Garage and Transit Center

Fair Oaks, VA

Photo Credit © Kate Wichlinski
2025 Winner
Photo Credit © Kate Wichlinski
Photo Credit © Kate Wichlinski
Photo Credit © Kate Wichlinski
Photo Credit © Kate Wichlinski
Photo Credit © Kate Wichlinski

    HGA

    Visit HGA Website

    Design Team:
    Jim Polhamus, AIA | Michael Schwartz, AIA | John Kemper, AIA | Austin Beck | Julian Master | Foad Shafighi

    General Contractor:
    Howard Shockey & Sons

    Additional Consultants:
    Walker - Parking Consultants | Gordon - Civil Engineering | S2B Structural - Structural Engineer | WELLS - Traffic Consultant | Weigand - MEP Engineering

    Project Description

    Design for Integration As part of the VDOT “Transform I-66 Outside the Beltway” initiative, the Monument Drive Parking Garage and Transit Center enhances multimodal transportation and commuter services. With 820 parking spaces, an eight-bay transit hub, and extensive pedestrian and cycling connections, the facility provides seamless integration between private vehicles, buses, and rideshare options, reducing congestion along I-66.

    Design for Equitable Communities Strategically located to serve Fairfax County, the garage supports access to employment centers such as Fair Oaks Mall and the Government Center Complex. The inclusion of Capital Bikeshare and dedicated pedestrian pathways enhances connectivity, while covered transit areas improve accessibility for all users, including those with mobility challenges.

    Design for Ecology The 3.82-acre site preserves existing natural elements, including a Tree Save area along Government Center Parkway. Landscaping features native and non-invasive plant species, promoting biodiversity and minimizing ecological disruption. Low Impact Development (LID) strategies, such as rain gardens and green roofs, further reduce stormwater runoff and improve environmental resilience.

    Design for Water Sustainable water management is central to the project, incorporating rainwater retention through the green roof and rain gardens. These elements reduce strain on municipal systems and support groundwater recharge, ensuring responsible water stewardship.

    Design for Economy At $40.8M, the project balances cost efficiency with high-performance design. The use of precast concrete construction optimized material costs while ensuring durability. Thoughtful sequencing of 800 precast components facilitated just-in-time delivery, eliminating the need for lay-down space and maintaining construction efficiency.

    Design for Energy The garage was the first to achieve Parksmart Silver certification in Virginia, featuring 75% NetZero energy consumption. Solar PV panels generate onsite power, LED lighting with occupancy sensors reduces energy demand, and electric vehicle charging stations encourage low-carbon transportation options.
    Design for Well-being The facility prioritizes safety through dedicated traffic circulation zones, high-visibility crosswalks, and pedestrian-safe zones with bollards. Enclosed stair towers with bird-friendly glazing provide natural daylighting, while a visually engaging design fosters a welcoming environment.

    Design for Resources Sustainable material choices include recycled aluminum cladding and precast concrete. Over 85% of construction waste was recycled. The bus canopy, made of steel and glass, balances durability with aesthetic appeal, while the steel cornice assembly provides long-term structural resilience.

    Design for Change Future adaptability is embedded in the design. The transit center is envisioned as a flexible civic space for county events, markets, and festivals. The structure’s modular layout allows for evolving transit needs and increasing demand for electric vehicle infrastructure.

    Design for Discovery The project serves as a regional model for sustainable transit-oriented design. Its integration of multimodal transportation, energy efficiency, and ecological preservation sets a precedent for future infrastructure projects, demonstrating a holistic approach to public mobility solutions.
